Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QJL22200
QJL22200 is a Square D 2 pole molded case circuit breaker rated for 200 amps and 240 volts AC with a thermal magnetic trip unit.This circuit breaker features a QJL frame type with a 100 kA interrupting rating at 240 VAC, providing reliable overload and short circuit protection. It is unit mounted and UL, CSA, and CE certified, suitable for industrial and commercial applications requiring high interrupt capacity and durability.
- Amperage: 200A
- Voltage: 240 VAC
- Poles: 2
- Frame Type: QJL
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 100 kA at 240 VAC
- Mounting Type: Unit Mount
- Certifications: UL, CSA, CE
- Phase: Single Phase
- Non-Interchangeable Trip
- Line & Load Side Lug Terminals
Specifications
- Part Number: QJL22200
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : QJL
- Voltage : 240
- Amperage : 200
- Phase : 1
- Poles : 2
- AIC rating : 100kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Frame Size : Q
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 785901760702
- GTIN : 00785901760702
- Country of Origin : Mexico
- Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
- Weight : 3.35
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
- Certification : UL, CSA, NOM
