QJL22125 - Square D Q Frame 125 Amp 2 Pole Molded Case Circuit Breaker 240V Feed-Thru Thermal Magnetic

QJL22125

QJL22125 is a 2 pole, 125 amp, 240V molded case circuit breaker designed for reliable thermal magnetic protection in commercial and industrial applications. This Square D Q Frame breaker features a feed-thru connection, extra high interrupting capacity, and is UL listed for safety and compliance. The unit includes non-interchangeable trip and line & load side lug terminals for secure installation.

• Part Number: QJL22125
• Manufacturer: Square D
• Series/Frame: Q Frame
• Amperage: 125 Amps
• Voltage: 240V AC
• Poles: 2 Pole
• Mounting Type: Unit Mount
• Interrupt Rating: 100kA @ 240V
• Trip Unit: LI - Long-Time and Instantaneous
• Protection Type: Thermal Magnetic
• Connection: Feed-Thru
• Certifications: UL, CSA, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QJL22125
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : QJL
• Voltage : 240
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : Q Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901705581
• GTIN : 00785901705581
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 3.35
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
