QJA222001 - Square D 200 Amp 240V 2-Pole Thermal Magnetic Circuit Breaker I-Line Plug-In

QJA222001

QJA222001 is a Square D 2-pole thermal magnetic molded case circuit breaker rated for 200 Amps and 240VAC voltage. It features an I-Line style plug-in connection for easy installation.

This circuit breaker provides reliable overcurrent protection with a 100kA interrupting rating at 240V. It includes long time and instantaneous trip functions and is designed for use in AC systems. The breaker meets multiple certifications including UL, CSA, NEMA, NOM, ANCE, IEC, and RoHS standards, ensuring safety and compliance. It has load side lug terminal connections and operates within a temperature range of 40 to 70°C.

• Manufacturer: Square D
• Part Number: QJA222001
• Amperage: 200 Amps
• Voltage: 240 VAC
• Poles: 2
• Interrupting Rating: 100kAIC @ 240V
• Connection Type: I-Line Style Plug-In
• Protection Type: Thermal Magnetic
• Trip Functions: Long Time and Instantaneous
• Terminal Connection: Load side lug
• Series/Frame: QJA
• Certifications: UL, CSA, NEMA, NOM, ANCE, IEC, RoHS

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QJA222001
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : QJA
• Voltage : 240
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901484325
• GTIN : 00785901484325
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 4.729
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
