Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QJA221001
QJA221001 is a 2 pole, 240VAC, 100A rated I-Line plug-in circuit breaker designed for reliable overcurrent protection in industrial and commercial power distribution systems.This Square D PowerPact Q-frame breaker features a thermal magnetic trip unit and a high interrupting capacity of 100kA at 240VAC, making it suitable for demanding applications requiring robust circuit protection. The I-Line plug-in mounting style ensures quick and secure installation in compatible panels.
- Part Number: QJA221001
- Manufacturer: Square D
- Series/Frame: PowerPact Q
- Amperage: 100A
- Voltage: 240VAC
- Poles: 2
- Mounting Type: I-Line Plug-In
- Interrupt Rating: 100kA @ 240VAC
- Trip Unit: Thermal Magnetic
- Application: Industrial/Commercial Power Distribution
- Standards: UL Listed, CSA Certified
- Warranty: Manufacturer Standard
Specifications
- Part Number: QJA221001
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : I-Line
- Type : QJA
- Voltage : 240
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 100kA@240V
- Connection : I-Line Style Plug-In
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- Country of Origin : Mexico
- Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
- Weight : 4.707
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
- Certification : UL, CSA, NOM
