QJA220701 - Square D 70A 2P 240VAC 100kAIC Type QJA PowerPact I-Line Circuit Breaker

QJA220701

QJA220701 is a Square D 70 Amp 2 Pole 240 Volt AC circuit breaker designed for reliable power distribution protection.QJA220701 features a 100kA interrupt rating at 240VAC, Type QJA frame, and PowerPact I-Line mounting. It uses a thermal magnetic trip unit and is UL and CSA certified for safety and performance.

• Amperage: 70A
• Voltage: 240VAC
• Poles: 2
• Interrupt Rating: 100kA at 240VAC
• Frame/Series: Type QJA PowerPact
• Mounting Type: I-Line
• Trip Unit: Thermal Magnetic
• Certifications: UL, CSA
• Application: Panelboard and Switchboard
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QJA220701
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : QJA
• Voltage : 240
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 4.751
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
