Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
QHCX2015
QHCX2015 is a 2 pole, 15 amp rated thermal magnetic circuit breaker designed for industrial and commercial power distribution applications. This QUICKLAG series breaker operates at 120/240 VAC and features cable-in/cable-out mounting for flexible installation in electrical panels and distribution systems. The breaker delivers reliable overcurrent protection with thermal magnetic trip technology suitable for general purpose and fluorescent lighting applications.Key Specifications
- Part Number: QHCX2015
- Manufacturer: Cutler Hammer (Eaton)
- Amperage Rating: 15 A
- Voltage Rating: 120/240 VAC
- Poles: 2
- Trip Type: Thermal Magnetic
- Interrupting Rating: 42000 A (42 kA)
- Series: QUICKLAG QHCX
- Mounting: Cable-In/Cable-Out
- Certifications: UL 489, CSA
- Dimensions: Height 4.8 IN, Length 3.8 IN, Width 0.75 IN
Specifications
- Part Number: QHCX2015
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QUICKLAG
- Type : QHCX
- Voltage : 240
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 42kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786679151594
- GTIN : 00786679151594
- Dimensions : 3.8 in x 4.8 in x 0.75 in (Length/Depth x Height x Width)
- Weight : 2.3
