QHB130 - Square D 30 Amp 1 Pole 120/240V Bolt-On Circuit Breaker 65kA Interrupt Rating

QHB130

QHB130 is a Square D 1 pole, 30 amp circuit breaker designed for bolt-on mounting with a 120/240 volt rating and 65kA interrupt capacity.This thermal magnetic molded case circuit breaker is HACR rated and suitable for use in panelboards requiring reliable overcurrent protection. It features a standard trip unit and is UL and CSA certified for safety and performance.

Key Specifications
• Amperage: 30 Amp
• Voltage Rating: 120/240 VAC
• Poles: 1 Pole
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA
• Trip Unit: Thermal Magnetic
• Series/Frame: QO
• Certifications: UL, CSA
• Application: HACR Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QHB130
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QHB
• Voltage : 120
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 65kA@120V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Pressure Plate
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 8 AWG (Cu/Al)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 785901255390
• GTIN : 00785901255390
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.3
• Standards : UL Listed, CSA
• Certification : UL Listed, CSA
