QGL22090 - Square D PowerPact Q Frame 2-Pole 90A 240V Molded Case Circuit Breaker 65kA Interrupt Rating

QGL22090

QGL22090 is a Square D PowerPact Q Frame molded case circuit breaker designed for 2-pole, 90 ampere, 240 volt AC applications with a 65kA interrupt rating.This circuit breaker features a thermal-magnetic trip unit providing reliable overload and short circuit protection. It is designed for unit mount on plate with lugs on both load and line sides, rated for 80% continuous current. The breaker complies with UL489 standards and has a frame current rating of 250 AF. It is suitable for industrial and commercial power distribution systems.

• Amperage: 90A
• Voltage Rating: 240 VAC
• Poles: 2
• Mounting Type: Unit Mount
• Interrupt Rating: 65kA at 240 VAC
• Series/Frame: PowerPact Q Frame 250
• Trip Unit: Thermal-Magnetic (fixed)
• UL Listed (UL489)
• Line and Load Lugs
• 80% Rated Continuous Current
• Dimensions: Approx. 114 mm H x 164 mm W x 100 mm D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QGL22090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : QGL
• Voltage : 240
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : Q Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78590111208
• GTIN : 00785901112082
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 1.52
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
