QGA220701 - Square D I-Line 2 Pole 70A 240VAC Circuit Breaker 65kAIC Thermal Magnetic

QGA220701

QGA220701 is a 2 pole, 70 amp, 240VAC molded case circuit breaker designed for I-Line panelboards and switchboards, featuring thermal magnetic protection and a high interrupting rating. This Square D QGA220701 circuit breaker is part of the PowerPact Q series, built for reliable distribution applications. It features an I-Line bracket mounting style, plug-in connection, and is suitable for use in both commercial and industrial environments. The breaker provides long time and instantaneous trip functions for comprehensive circuit protection.

• Part Number: QGA220701
• Manufacturer: Square D
• Series: PowerPact Q
• Poles: 2
• Amperage: 70A
• Voltage: 240VAC
• Interrupting Rating: 65kAIC at 120/240VAC
• Mounting Type: I-Line Bracket
• Connection Type: I-Line Style Plug-In
• Protection Type: Thermal Magnetic
• Functions: Long Time and Instantaneous Trip
• Certifications: UL, CSA, NEMA, NOM

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QGA220701
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : QGA
• Voltage : 240
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901466505
• GTIN : 00785901466505
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 4.729
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
