QF240A - Siemens 40 Amp 120/240V 2-Pole Ground Fault Circuit Breaker Plug-On Q Frame

QF240A

QF240A is a Siemens 2-pole ground fault circuit breaker rated for 40 amps and 120/240 volts AC, designed for plug-on mounting in Siemens load centers.

This circuit breaker features a thermal magnetic trip unit with long-time and instantaneous trip functions, a 10kA interrupting rating at 120/240VAC, and a 5mA ground fault trip sensitivity. It has lug-type terminals supporting wire sizes from 8 to 6 AWG and is UL listed, CSA certified, and HACR rated for residential and commercial applications.

Key Specifications
• Amperage: 40 Amps
• Voltage Rating: 120/240 VAC
• Number of Poles: 2
• Mounting Type: Plug-On
• Interrupting Rating: 10 kAIC at 120/240 VAC
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
• Ground Fault Trip Sensitivity: 5 mA
• Terminal Type: Lug
• Wire Size Range: 8-6 AWG
• Series/Frame: Q Frame
• Certifications: UL Listed, CSA Certified, HACR Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QF240A
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Q Series
• Type : QPF
• Voltage : 120/240
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 225A/QF
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 6 AWG
• Breaker Type : Ground Fault Circuit Interrupter (Class A - 5mA)
• Protection : Thermal Magnetic

Product Data

• UPC : 887621216726
• GTIN : 00887621216726
• Country of Origin : Philippines
• Dimensions : 6.693 x 1.969 x 2.756 inch
• Weight : 0.992
• Panel Type : Siemens Load Centers
• Standards : CSA Certified, UL Listed
• Certification : CSA Certified, UL Listed
• Wire Size : 14 - 10 AWG (Copper) 12 - 8 AWG (Aluminium)
