Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QDM22125TN
QDM22125TN is a Schneider Electric 2 pole, 125 amp, 240 Volt PowerPact QDM molded case circuit breaker with a 25kA interrupt rating and bolt-on mounting.This circuit breaker features a thermal-magnetic trip unit with fixed 125A trip current, designed for panelboard or switchboard applications. It has a 2-pole configuration, 240VAC rated voltage, and a frame rating of 250A. The breaker uses bolt-on mounting with threaded studs on the load side and lugs on the line side. It provides reliable overcurrent protection with a 25kA interrupting capacity at 240V and is UL489 certified.
- Amperage: 125A
- Voltage: 240VAC
- Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 25kA @ 240V
- Frame: PowerPact QDM 250A
- Trip Unit: Thermal-Magnetic (fixed)
- Connection: Threaded studs (load), lugs (line)
- Certifications: UL489
- Rated Current: 125A
- Rated Operating Voltage: 240V
- Protection: Overload and short-circuit
Specifications
- Part Number: QDM22125TN
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : QDM
- Voltage : 240
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 25kA@240V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 78590141872
- GTIN : 00785901418726
- Country of Origin : Mexico
- Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
- Weight : 3.26
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
- Certification : UL, CSA, NOM
