QDA32090 - Square D 90A 240VAC 3 Pole I-Line Molded Case Circuit Breaker, PowerPacT Q Series, 25kAIC, Thermal Magnetic Trip, UL/CSA/NEMA Certified

Save $1,134.26
SKU: QDA32090-New
Condition: New
Price:
$934.74 $2,069.00
Stock:
4 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

QDA32090 - Square D I-Line Style Plug-In 240V 90A 3 pole circuit breaker 25kA@240V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
QDA32090 - Square D I-Line Style Plug-In 240V 90A 3 pole circuit breaker 25kA@240V - Essential Electric Supply

Description

QDA32090


QDA32090 is a Square D 3 pole molded case circuit breaker designed for reliable protection in commercial and industrial power distribution.

This thermal magnetic circuit breaker features a 90A current rating, 240VAC voltage rating, and 25kAIC interrupting capacity. It is part of the PowerPacT Q series, with an I-Line plug-in mounting style for easy installation in compatible panelboards. The breaker includes long time and instantaneous trip functions, supports both copper and aluminum conductors, and is certified to major North American and international standards.

    Key Specifications
  • Amperage: 90A
  • Voltage: 240VAC
  • Poles: 3
  • Mounting Type: I-Line bracket (plug-in)
  • Interrupt Rating: 25kAIC at 240VAC
  • Series/Frame: PowerPacT Q, QDA frame
  • Trip Unit: Thermal magnetic, long time and instantaneous trip
  • Certifications: UL, CSA, NEMA, NOM, IEC, RoHS, REACh, HACR
  • Wire Range: AWG 4 to 300 kcmil (aluminum/copper)
  • Temperature Rating: 40 to 70°C (104°F max)
  • Connection: Load side lugs
  • For Use With: I-Line panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

  • Part Number: QDA32090
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : I-Line
  • Type : QDA
  • Voltage : 240
  • Amperage : 90
  • Phase : 3
  • Poles : 3
  • AIC rating : 25kA@240V
  • Connection : I-Line Style Plug-In
  • Functions : Long Time and Instantaneous Trip
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901832904
  • Country of Origin : Mexico
  • Dimensions : 6.47 in (164.34 mm) x 4.5 in (114.3 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
  • Weight : 6.669 lb
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
  • Certification : UL, CSA, NOM
  • Wire Size : AWG 4 to 300KCmil, Aluminum/Copper
