QDA221102 - Square D 110A 240V 2 Pole Molded Case Circuit Breaker I-Line Plug-In 25kA Interrupt Rating

QDA221102

QDA221102 is a Square D molded case circuit breaker designed for power distribution applications requiring reliable protection.This 2 pole, 110 amp, 240 volt AC breaker features a thermal magnetic trip unit with long-time and instantaneous trip functions. It is part of the I-Line family with a plug-in mounting style and a 25kA interrupting rating at 240V. UL and CSA certified, it is suitable for single-phase systems and includes load side lug terminals.

• Manufacturer: Square D
• Part Number: QDA221102
• Amperage: 110 A
• Voltage Rating: 240 V AC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 25kA @ 240V
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Phase: Single Phase
• Frame/Series: QDA (I-Line Family)
• Certifications: UL Listed, CSA Approved
• Dimensions (HxWxD): 6.47 x 3.93 x 3 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QDA221102
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : QDA
• Voltage : 240
• Amperage : 110
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901492870
• GTIN : 00785901492870
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 4.65
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
• Wire Size : AWG 4 to 300KCmil, Aluminum/Copper
