QCGFT2050 - Cutler Hammer 50A 240V 2 Pole Thermal Magnetic Circuit Breaker Feed-Thru 10kAIC

QCGFT2050

QCGFT2050 is a Cutler Hammer 2 pole, 50 amp, 240 volt thermal magnetic circuit breaker with feed-thru connection and 10kA interrupting rating.The QCGFT2050 features a molded case design with long-time and instantaneous trip functions, cable in/cable out mounting type, and ground fault self-test capability. It is UL and CSA certified for reliable circuit protection in industrial and commercial applications.

• Manufacturer: Cutler Hammer (Eaton)
• Series/Frame: QC
• Amperage: 50 A
• Voltage: 240 V
• Poles: 2
• Mounting Type: Cable in/Cable out (Feed-Thru)
• Interrupt Rating: 10kA @ 240 V
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous)
• Certifications: UL 489, UL 943, CSA
• Wire Gauge: #14 to 4 AWG Cu/Al
• Dimensions (HxWxD): 3.1" x 4.4" x 5.7"
• Weight: Approx. 0.8 to 1.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QCGFT2050
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QC Series
• Type : QCGFT
• Voltage : 240
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786676026659
• GTIN : 00786676026659
• Country of Origin : Dominican Republic
• Dimensions : 5.7 in x 3.1 in x 4.4 in (Length/Depth x Height x Width)
• Weight : 0.8
• Certification : UL 489,UL 943
• Wire Size : 14 to 4 AWG Cu/Al
