Q130 - Siemens 30 Amp 1 Pole 120V 10kA QP Series Plug-In Circuit Breaker, Thermal Magnetic Trip, UL Listed, HACR Rated

Q130

Q130 is a Siemens 30 Amp, 1 Pole, 120V plug-in circuit breaker designed for reliable branch circuit protection in residential and commercial applications.

This thermal magnetic circuit breaker features a 10,000 Amp interrupting rating, plug-in mounting for easy installation in Siemens QP series load centers, and is UL listed and HACR rated for safety and compliance. The Q130 offers both long-time and instantaneous trip protection, ensuring equipment and personnel safety.

Key Specifications
• Amperage: 30A
• Voltage: 120VAC, 48VDC
• Poles: 1
• Mounting Type: Plug-In
• Interrupt Rating: 10,000A (10kA) at 120VAC
• Series/Frame: Q/ QP
• Trip Unit: Thermal Magnetic (Fixed Trip)
• Certifications: UL Listed, HACR Rated, CSA Approved
• Dimensions: 3" H x 1" W x 3" L
• Wire Size: 14 to 8 AWG (Min to Max)
• Actuator Type: Toggle
• For Use With: Siemens EQ, EQL, SEQ, EQG, PL, ES series load centers

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: Q130
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Q Series
• Type : QP
• Voltage : 120
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/QP
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 8 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643148215
• GTIN : 00783643148215
• Country of Origin : Mexico
• Dimensions : 12.598 x 3.15 x 3.15 inch
• Weight : 0.265
• Panel Type : Siemens EQ Load Centers
• Standards : UL Listed
• Certification : UL Listed
