PVML-9-UNV1 - Eaton Lighting and controls LED Fixture 9000 Lumens

SKU: PVML-9-UNV1-New
Condition: New
Price:
Call For Price
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

Essential Electric Default Product Image

Description

PVML-9-UNV1


PVML-9-UNV1 is an Eaton Crouse-Hinds series Champ Pro LED light fixture designed for industrial mid-bay and high-bay downlighting applications. Technical Description: This fixture delivers 9000 lumens with 123 lumens per watt efficiency, equivalent to a 250W HID lamp. It features cool white color temperature, Type V optical distribution, and a die-cast aluminum housing with heat and impact-resistant glass lens. The fixture is NEMA 4X rated with IP66 ingress protection, suitable for extremely corrosive, wet, dusty, hot, and cold environments. It operates at 100-277 Vac or 127-250 Vdc with 50/60 Hz frequency and includes a dimmable driver with power factor greater than 0.90. Key Specifications
  • Part Number: PVML-9-UNV1
  • Manufacturer: Eaton
  • Lumens: 9000
  • Lumens per Watt: 123
  • Color Temperature: Cool white
  • Voltage Rating: 100-277 Vac, 127-250 Vdc
  • Wattage: 75 W
  • Optical Distribution: Type V
  • NEMA Rating: 4X
  • IP Rating: IP66
  • Mounting Method: Stanchion 25° angled
  • Material: Die cast aluminum
  • Lens Material: Heat and impact resistant glass
  • Dimming: Dimmable driver
  • Power Factor: Greater than 0.90
  • Frequency: 50/60 Hz
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: PVML-9-UNV1
  • Manufacturer : Eaton
  • Brand : Eaton
  • Category : Lighting and controls
  • Item Subcategory : Highbay, lowbay and industrials
  • Voltage : 100-277 V
  • Nema Rating : 4X
  • Watts : 75
  • Hz : 50/60
  • Protection : IP66
  • Material : Die cast aluminum
  • Ingress protection (IP) ratings : IP66
  • Lumens : 9000
  • Lumens per watt : 123
  • Color temperature : Cool white
  • Mounting Method : Stanchion 25° angled
  • Equivalent luminaire : 250W HID
  • Guard type : No guard
  • Dimming : Dimmable driver
  • Power factor : Greater than 0.90

Product Data

  • UPC : 662276890626
  • Dimensions : 13 in x 13.13 in x 12.75 in (Length/Depth x Height x Width)
  • Weight : 20.8 lb
