PLA34100U44A - Schneider Electric PowerPact P 1000A 3 Pole 480V I-Line Style Circuit Breaker 100kA Interrupt Rating

PLA34100U44A

PLA34100U44A is a Schneider Electric PowerPact P molded case circuit breaker designed for 480 Volt systems with a 1000 Amp rating and 3 poles in an I-Line style plug-in configuration.This circuit breaker features a high interrupting capacity of 100kA at 480V, suitable for demanding industrial applications. It includes a Micrologic 6.0A trip unit with LSIG (Long-Time, Short-Time, Instantaneous, and Ground Fault) protection functions. The breaker is UL listed, CSA NMX certified, and IEC compliant, ensuring global standards compliance. It supports 3-phase power distribution with robust construction for reliable performance.

• Amperage: 1000A
• Voltage: 480V
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 100kA at 480V
• Series/Frame: PowerPact P
• Trip Unit: Micrologic 6.0A LSIG
• Certifications: UL 489 Listed, CSA NMX, IEC 60947-2
• Connection: 3 Phase
• Application: Molded Case Circuit Breaker for industrial power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PLA34100U44A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PLA
• Voltage : 480
• Amperage : 1000
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Protection : Solid State

Product Data

• UPC : 762179036760
• Dimensions : 16.16 in (410.46 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32 lb
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0...500 kcmil aluminium/copper
