PJA36080U64AE1 - Schneider Electric PowerPact P Molded Case Circuit Breaker 800A 600VAC 3 Pole Micrologic 6.0P Trip

PJA36080U64AE1

PJA36080U64AE1 is a Schneider Electric PowerPact P molded case circuit breaker designed for reliable power distribution protection.This 3-pole circuit breaker features an 800 ampere rating, 600 VAC voltage rating, and a 25 kA interrupting capacity. It includes the advanced Micrologic 6.0P electronic trip unit for precise protection and control. The breaker is I-Line mounted and supports 100% continuous current rating, suitable for demanding industrial and commercial applications.

• Manufacturer: Schneider Electric
• Series: PowerPact P
• Type: Molded Case Circuit Breaker
• Poles: 3
• Amperage: 800 A
• Voltage Rating: 600 VAC
• Interrupt Rating: 25 kA
• Trip Unit: Micrologic 6.0P Electronic
• Mounting Type: I-Line
• Continuous Current Rating: 100%
• Certifications: Industry standard certifications (UL, IEC compliant)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PJA36080U64AE1
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PJA
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : AL800M23K
• Frame Size : P Frame
• Temp Rating : 13-158 °F (-25-70 °C)
• Protection : Solid State

Product Data

• UPC : 060648628541
• GTIN : 03606486285411
• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
