PJA36080U63AE1 - Square D 800A 600V 3-Pole Molded Case Circuit Breaker Powerpact

PJA36080U63AE1

PJA36080U63AE1 is a Square D 3-pole molded case circuit breaker designed for 800 ampere and 600 volt applications.This Powerpact series breaker features an electronic trip unit with MicroLogic 5.0 P and LSI protection, suitable for high-performance power distribution. It has a frame rating of 1200A and an interrupt rating up to 100kA at 240VAC, ensuring reliable fault interruption. The breaker is UL listed and designed for industrial and commercial electrical systems.

• Amperage: 800A trip, 1200A frame
• Voltage Rating: 600V
• Poles: 3
• Mounting Type: Molded Case
• Interrupt Rating: 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC
• Series/Frame: Powerpact PJA
• Trip Unit: Electronic, MicroLogic 5.0 P, LSI
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PJA36080U63AE1
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PJA
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Terminal Connection : AL800M23K
• Frame Size : P Frame
• Temp Rating : 13-158 °F (-25-70 °C)
• Protection : Solid State

Product Data

• UPC : 785901657958
• GTIN : 00785901657958
• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
