PJA36080CU44A - Schneider Electric PowerPact PJA 800A 600V 3 Pole Molded Case Circuit Breaker with Micrologic 6.0A Trip Unit

Save $15,250.10
SKU: PJA36080CU44A-New
Condition: New
Price:
$12,807.90 $28,058.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

PJA36080CU44A - Square D I-Line Style Plug-In 600V 800A 3 pole circuit breaker 65kA@480V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
PJA36080CU44A - Square D I-Line Style Plug-In 600V 800A 3 pole circuit breaker 65kA@480V - Essential Electric Supply

Description

PJA36080CU44A


PJA36080CU44A is a Schneider Electric PowerPact PJA series molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 3-pole configuration, 800A current rating, and 600V AC voltage rating, making it suitable for demanding applications. The advanced Micrologic 6.0A trip unit provides LSIG (Long-Time, Short-Time, Instantaneous, Ground-Fault) protection for precise fault detection and system safety. The breaker is DIN rail mountable and offers a high interrupt rating for robust performance. Key Specifications
  • Part Number: PJA36080CU44A
  • Manufacturer: Schneider Electric
  • Series/Frame: PowerPact PJA
  • Amperage: 800A
  • Voltage: 600V AC
  • Poles: 3
  • Mounting Type: DIN Rail
  • Interrupt Rating: 100kA @ 240VAC, 65kA @ 480VAC
  • Trip Unit: Micrologic 6.0A (LSIG)
  • Breaker Type: Solid State
  • Actuator Type: Toggle
  • Certifications: UL Listed, CSA Certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: PJA36080CU44A
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : PJA
  • Voltage : 600
  • Amperage : 800
  • Phase : 3
  • Poles : 3
  • AIC rating : 65kA@480V
  • Connection : I-Line Style Plug-In
  • Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
  • Terminal Connection : AL800M23K
  • Frame Size : P Frame
  • Temp Rating : 13-158 °F (-25-70 °C)
  • Protection : Solid State

Product Data

  • UPC : 785901497141
  • GTIN : 00785901497141
  • Country of Origin : Mexico
  • Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
  • Weight : 37.26
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
