Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
PJA36060U44AYP
PJA36060U44AYP is a 3-pole molded case circuit breaker from Square D, designed for reliable power distribution with a 600 ampere rating and 600 volt capacity.This PowerPact I-Line breaker features a P-frame design with a solid state trip unit, suitable for industrial and commercial applications requiring high interrupt ratings and flexible mounting options.
- Key Specifications
- Amperage: 600 A
- Voltage Rating: 600 V AC
- Poles: 3
- Frame Type: P-frame
- Series: PowerPact I-Line
- Interrupt Rating: 100 kA at 240 V, 65 kA at 480 V
- Mounting Type: I-Line
- Trip Unit: LSIG (Long-time, Short-time, Instantaneous, Ground fault)
- Frequency: 50/60 Hz
- Enclosure Type: NEMA AB1
- Certifications: UL Listed, CSA Certified
- Part Number: PJA36060U44AYP
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : PJA
- Voltage : 600
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : I-Line Style Plug-In
- Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
- Terminal Connection : AL800M23K
- Frame Size : P Frame
- Temp Rating : 13-158 °F (-25-70 °C)
- Protection : Solid State
- UPC : 762179029724
- Country of Origin : United States
- Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
- Weight : 32
- Certification : CE, UL, CSA, NEMA, NOM, IEC, RoHS
