PJA36060U44AE1 - Square D 600A 600V 3 Pole I-Line Style Circuit Breaker 65kA Interrupt Rating

PJA36060U44AE1

PJA36060U44AE1 is a Square D 3 pole, 600 Volt, 600 Amp I-Line style molded case circuit breaker with a 65kA interrupting rating at 480V.This circuit breaker features a plug-in mounting type designed for industrial and commercial applications. It provides reliable protection with a 65kA interrupting capacity at 480V, suitable for high fault current environments. The breaker is UL 489, CSA, and IEC certified, ensuring compliance with industry safety standards.

• Amperage: 600 Amps
• Voltage Rating: 600 Volts
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 65kA at 480V
• Series/Frame: I-Line
• Trip Unit: LSIG (Long-time, Short-time, Instantaneous, Ground fault)
• Certifications: UL 489, CSA, IEC
• Application: Industrial and commercial power distribution
• Compatible with Square D I-Line panels

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PJA36060U44AE1
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PJA
• Voltage : 600
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : AL800M23K
• Frame Size : P Frame
• Temp Rating : 13-158 °F (-25-70 °C)
• Protection : Solid State

Product Data

• UPC : 785901069225
• Country of Origin : United States
• Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
• Weight : 32
• Certification : CE, UL, CSA, NEMA, NOM, IEC, RoHS
