PGA36120U43A - Schneider Electric PowerPact P 1200A 3P 600VAC 18kA I-Line Molded Case Circuit Breaker with Micrologic 5.0A Trip Unit

PGA36120U43A

PGA36120U43A is a Schneider Electric PowerPact P-frame molded case circuit breaker designed for robust power distribution applications.

This 3-pole breaker offers a 1200A current rating, 600VAC voltage rating, and an 18kA interrupting capacity at 600VAC. It features a Micrologic 5.0A electronic trip unit for advanced protection, is rated for 80% continuous current, and uses an I-Line plug-in connection for easy installation. The breaker is UL Listed, IEC, and CSA certified for compliance with international standards.

Key Specifications

• Amperage: 1200A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: I-Line (plug-in busbar)
• Interrupt Rating: 18kA at 600VAC
• Series/Frame: PowerPact P
• Trip Unit: Micrologic 5.0A (LSI)
• Continuous Rating: 80%
• Connection: I-Line style
• Certifications: UL Listed, IEC, CSA
• Dimensions: 16.16 in H x 8.27 in W x 8.05 in D
• Weight: 32 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PGA36120U43A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PGA
• Voltage : 600
• Amperage : 1200
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time, Short Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901854418
• GTIN : 00785901854418
• Country of Origin : Mexico
• Dimensions : 16.16 in (410.46 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 35.609
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0...500 kcmil aluminium/copper
