PGA36080CU31A - Square D PowerPact PGA 800A 600V 3 Pole Molded Case Circuit Breaker I-Line Plug-In

Save $5,887.39
SKU: PGA36080CU31A-New
Condition: New
Price:
$16,591.61 $22,479.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

PGA36080CU31A - Square D I-Line Style Plug-In 600V 800A 3 pole circuit breaker 35kA@480V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
PGA36080CU31A - Square D I-Line Style Plug-In 600V 800A 3 pole circuit breaker 35kA@480V - Essential Electric Supply

Description

PGA36080CU31A


PGA36080CU31A is a Square D PowerPact PGA series 3 pole molded case circuit breaker rated for 800A and 600V, designed for I-Line plug-in mounting in power distribution applications. This breaker features solid state electronic trip technology with LI (Long-Time and Instantaneous) protection, suitable for use in I-Line panelboards and switchboards. It is certified to UL, CSA, and IEC standards for reliable performance in commercial and industrial environments.
  • Part Number: PGA36080CU31A
  • Manufacturer: Square D
  • Series/Frame: PowerPact PGA
  • Amperage: 800A
  • Voltage: 600V AC
  • Poles: 3
  • Mounting Type: I-Line Plug-In
  • Interrupt Rating: 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC
  • Trip Unit: LI (Long-Time and Instantaneous)
  • Protection Type: Solid State Electronic
  • Approvals: UL, CSA, IEC
  • Application: Power Distribution, Panelboards, Switchboards
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: PGA36080CU31A
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : PGA
  • Voltage : 600
  • Amperage : 800
  • Phase : 3
  • Poles : 3
  • AIC rating : 35kA@480V
  • Connection : I-Line Style Plug-In
  • Functions : LI - Long-Time and Instantaneous
  • Protection : Solid State

Product Data

  • UPC : 785901574309
  • GTIN : 785901574309
  • Country of Origin : Mexico
  • Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
  • Weight : 32
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
