PDG5XPXR31200E5R - Eaton Power Defense 1200A 600V 3-Pole Circuit Breaker Trip Unit Frame 5 JK PXR20 LSIG ARMS

PDG5XPXR31200E5R

PDG5XPXR31200E5R is an Eaton Power Defense molded case circuit breaker trip unit designed for reliable electrical protection in industrial and commercial applications.This trip unit features a 1200 ampere rating, three poles, and supports up to 600 volts. It is part of Eaton's Power Defense series with a Frame 5 JK size and includes the PXR20 LSIG ARMS trip type, providing long-time, short-time, instantaneous, and ground fault protection. The unit is RoHS compliant and certified to IEC 60947-2, CCC, CSA, and UL 489 standards.

• Amperage Rating: 1200 A
• Voltage Rating: 600 V max
• Number of Poles: Three-pole
• Frame Size: Frame 5 JK
• Series: Power Defense
• Trip Type: PXR20 LSIG ARMS (Long-time, Short-time, Instantaneous, Ground Fault)
• Circuit Breaker Type: PD5 Global
• Communication: Relays
• Certifications: IEC 60947-2, CCC, CSA, UL 489
• Compliance: RoHS Compliant
• Product Weight: 1 kg
• Dimensions (HxWxD): 82.6 mm x 139.7 mm x 206.4 mm

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG5XPXR31200E5R
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Poles : 3
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Protection : Solid State
• Compatible Frames : PDG,PDF,PDJ Frame 5

Product Data

• UPC : 786679600900
• GTIN : 00786679600900
• Dimensions : 206.4 mm x 82.6 mm x 139.7 mm (Length/Depth x Height x Width)
• Weight : 2.23
