PDG3XTFA30500 - Cutler Hammer 3 Pole 500A 600V Power Defense Circuit Breaker Trip Unit Frame J-K

PDG3XTFA30500

PDG3XTFA30500 is a Cutler Hammer Power Defense trip unit designed for molded case circuit breakers with a 3 pole configuration and 500 amp rating.This trip unit operates at 600 volts AC and fits Frame J-K size breakers. It features thermal magnetic protection with long-time and instantaneous trip functions, ensuring reliable circuit interruption. The unit is UL 489, CSA, IEC 60947-2, and CCC certified and RoHS compliant.

• Amperage Rating: 500 A
• Voltage Rating: 600 VAC
• Number of Poles: Three-pole
• Frame Size: J-K (Frame 3)
• Series: Power Defense (PDG)
• Trip Unit Type: Thermal Magnetic
• Interrupt Rating: Compatible with PDG Frame breakers
• Certifications: UL 489, CSA, IEC 60947-2, CCC Marked
• RoHS Compliant
• Product Weight: 2.2 lb
• Dimensions: 8.31 in (L) x 5.18 in (W) x 4.18 in (H)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG3XTFA30500
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Power Defense Series
• Type : PDG
• Voltage : 600VAC
• Amperage : 500
• Poles : 3
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Amperage Maximum : 500
• Protection : Thermal Magnetic
• Compatible Frames : PDG

Product Data

• UPC : 786679589366
• GTIN : 786679589366
• Dimensions : 8.31 in x 4.18 in x 5.18 in (Length/Depth x Height x Width)
• Weight : 2.2 lb
• Standards : RoHS
• Certification : IEC, CSA, UL, CCC
