PDG3XTFA30225 - Cutler Hammer 225A 600V 3-Pole Power Defense Circuit Breaker Trip Unit Frame 3

PDG3XTFA30225

PDG3XTFA30225 is a Cutler Hammer Power Defense trip unit designed for molded case circuit breakers with a 225 Amp rating and 600 Volt capacity.This trip unit features a three-pole configuration, Frame 3 size, and is part of Eaton's PD3 Global Power Defense series. It provides reliable thermal magnetic protection and complies with UL 489, CSA, CCC, and IEC 60947-2 certifications. The unit is RoHS compliant and built for durability and safety in industrial power distribution.

• Amperage Rating: 225 A
• Voltage Rating: 600 V AC
• Number of Poles: Three-pole
• Frame: 3
• Series: Power Defense (PD3 Global)
• Trip Unit Type: Thermal Magnetic
• Certifications: UL 489, CSA, CCC, IEC 60947-2
• Compliance: RoHS Compliant
• Mounting Type: Molded Case Circuit Breaker Accessory
• Product Dimensions: 211.1 mm length, 106.4 mm height, 131.8 mm width

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG3XTFA30225
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Power Defense Series
• Type : PDG
• Voltage : 600VAC
• Amperage : 225
• Poles : 3
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Amperage Maximum : 225
• Protection : Thermal Magnetic
• Compatible Frames : PDG

Product Data

• UPC : 786679588802
• Dimensions : 211.1 mm x 106.4 mm x 131.8 mm (Length/Depth x Height x Width)
• Weight : 2.23
• Standards : RoHS
• Certification : IEC, CSA, UL, CCC
