Product Info
- Manufacturer:Eaton
- Sub-Category:Trip Units & Programmers
Description
PDG3XTFA30175
PDG3XTFA30175 is an Eaton Power Defense trip unit designed for circuit breakers with a 175 Amp rating and 600 VAC voltage capacity.This trip unit is a three-pole accessory compatible with Eaton's PD3 Global circuit breaker type, featuring a Frame J-K size within the Power Defense series. It provides reliable protection and precise trip functionality for industrial and commercial electrical systems.
- Amperage Rating: 175 Amps
- Voltage Rating: 600 VAC
- Poles: 3
- Frame Size: J-K
- Circuit Breaker Type: PD3 Global
- Series: Power Defense
- Trip Unit Accessory
- Mounting Type: Compatible with PDG frame breakers
- Interrupt Rating: Standard for Power Defense series
- Certifications: Eaton standard compliance
Specifications
- Part Number: PDG3XTFA30175
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : Power Defense Series
- Type : PDG
- Voltage : 600VAC
- Amperage : 175
- Poles : 3
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Amperage Maximum : 175
- Protection : Thermal Magnetic
- Compatible Frames : PDG
Product Data
- UPC : 786679588765
- GTIN : 00786679588765
- Dimensions : 211.1 mm x 106.4 mm x 131.8 mm (Length/Depth x Height x Width)
- Weight : 2.23
- Standards : RoHS
- Certification : IEC, CSA, UL, CCC
