Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG33M0600KNSJ
PDG33M0600KNSJ is a 3-pole molded case circuit breaker from Eaton's Power Defense series rated for 600 amps and 600 volts.
This circuit breaker features a Frame 3 design with a 65kA interrupting rating at 480V, thermal-magnetic trip unit, and standard line and load lug connections. It is UL 489 certified and suitable for global applications requiring reliable overcurrent protection in industrial and commercial power distribution systems.
- Key Specifications
- Amperage: 600 A
- Voltage Rating: 600 VAC / 250 VDC
- Poles: 3
- Frame Size: 3
- Interrupt Rating: 65kA at 480V
- Trip Unit: Thermal-magnetic
- Mounting Type: Molded case
- Certifications: UL 489
- Standard line and load lug connections
- Series: Power Defense Globally Rated
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: PDG33M0600KNSJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 600
- AIC rating : 65kA@480V
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679478370
- GTIN : 786679478370
- Country of Origin : Dominican Republic
- Dimensions : 109.1 mm x 257.1 mm x 138.9 mm (Length/Depth x Height x Width)
- Weight : 12.5103
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
