PDG33G0125TFAJ - Eaton Power Defense 125A 600V 3 Pole Molded Case Circuit Breaker Frame 3 T-M Trip Unit

PDG33G0125TFAJ

PDG33G0125TFAJ is a Power Defense Series molded case circuit breaker designed for reliable protection in low voltage distribution systems. This 3-pole breaker features a 125A current rating, 600VAC voltage rating, and a 35kA interrupt rating at 480VAC, making it suitable for demanding industrial and commercial applications. The breaker is equipped with a thermal-magnetic (T-M) trip unit for precise overcurrent protection and is globally rated for use in a wide range of environments. Its compact frame 3 design allows for easy installation and integration into existing panels. Engineered for durability and performance, the PDG33G0125TFAJ offers field-installable accessories and supports standard line/load terminal connections. Eaton's patented contact design ensures high-speed operation and superior interruption performance. This breaker is ideal for applications requiring robust circuit protection and compliance with international standards.

• Part Number: PDG33G0125TFAJ
• Manufacturer: Eaton
• Series: Power Defense
• Frame: 3
• Amperage Rating: 125A
• Voltage Rating: 600VAC
• Poles: 3
• Interrupt Rating: 35kA at 480VAC
• Mounting Type: Bolt-on
• Trip Unit: Thermal-Magnetic (T-M)
• Certifications: UL Listed, Globally Rated
• Application: Industrial, Commercial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG33G0125TFAJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78667953863
• GTIN : 00786679538630
• Dimensions : 109.1 mm x 257.1 mm x 138.9 mm (Length/Depth x Height x Width)
• Weight : 12.5103
