- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG23M0175TFFJ
PDG23M0175TFFJ is a 3-pole Eaton Power Defense molded case circuit breaker rated for 175 amps and 600 volts AC.This circuit breaker features a Frame 2 design with thermal magnetic trip unit (fixed-fixed), providing reliable protection with a 65kA interrupt rating at 480VAC. It uses bolt-on mounting and is suitable for industrial and commercial power distribution applications. Certified globally, it ensures safety and compliance with electrical standards.
- Amperage: 175 A
- Voltage Rating: 600 VAC
- Poles: 3
- Frame: 2 (Power Defense series)
- Trip Unit: Thermal Magnetic (Fixed-Fixed)
- Interrupt Rating: 65 kA at 480 VAC
- Mounting Type: Bolt-On
- Circuit Breaker Type: Molded Case
- Global Certifications
- Standard Line and Load Terminals
Specifications
- Part Number: PDG23M0175TFFJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 175
- Phase : 3
- AIC rating : 65kA@480V
- Functions : LI - Long Time and Instantaneous Trip
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679206218
- GTIN : 00786679206218
- Country of Origin : Dominican Republic
- Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
- Weight : 4.0586
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 528
