PDG23M0150TFFL - Eaton Power Defense 3 Pole 150A 600VAC Molded Case Circuit Breaker, Frame 2, 65kAIC, Thermal Magnetic Trip, Bolt-On, CSA/UL/IEC/CCC Certified

PDG23M0150TFFL

PDG23M0150TFFL is a globally rated Eaton Power Defense molded case circuit breaker designed for robust electrical protection in commercial and industrial applications.

This 3-pole, 150A, 600VAC circuit breaker features a thermal magnetic trip unit with long-time and instantaneous protection, a 65kA interrupting rating at 480VAC, and a bolt-on (feed-thru) connection. It is part of the PD2 Global series, Frame 2, and is certified to CSA, UL, IEC, and CCC standards for reliable performance worldwide.

Key Specifications
• Amperage: 150A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Bolt-On (Feed-Thru)
• Interrupt Rating: 65kAIC at 480VAC
• Series/Frame: Power Defense PD2 Global, Frame 2
• Trip Unit: Thermal Magnetic (Long-Time & Instantaneous)
• Certifications: CSA, UL, IEC, CCC
• Connection: Standard load side lug
• Protection: Thermal Magnetic
• Standards: RoHS
• Complete Breaker: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23M0150TFFL
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078667985819
• GTIN : 00786679858196
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 527
