Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG23M0150MSAJ
PDG23M0150MSAJ is an Eaton Power Defense motor circuit protector designed for reliable motor protection in industrial applications.This circuit breaker features a Frame 2 design with a thermomagnetic trip unit, providing a 600 Vac voltage rating and an interrupt rating of 65 kAIC at 480 Vac. It is a 3-pole device rated for 150 amps, suitable for panel mounting and global applications.
- Key Specifications
- Manufacturer: Eaton
- Part Number: PDG23M0150MSAJ
- Type: Motor Circuit Protector
- Poles: 3
- Amperage: 150A
- Voltage Rating: 600 Vac
- Interrupt Rating: 65 kAIC at 480 Vac
- Frame: 2
- Trip Unit: Thermomagnetic
- Part Number: PDG23M0150MSAJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Section : Motor circuit protector
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 153
- AIC rating : 65kA@480V
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
- UPC : 786679321324
- Dimensions : 3.5 in x 6 in x 4.12 in (Length/Depth x Height x Width)
- Weight : 4.01
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 524
