PDG23M0150B2NL - Eaton 150 Amp 600 VAC 3 Pole Molded Case Circuit Breaker Frame 2 PXR10 LSI Trip

PDG23M0150B2NL

PDG23M0150B2NL is a 150 Amp, 600 VAC, 3 Pole molded case circuit breaker from Eaton's Power Defense series.PDG23M0150B2NL features a Frame 2 design with a PXR10 LSI trip unit, providing reliable protection with a 65 kA interrupt rating at 480V. This breaker is designed for global applications with standard load and line terminals and solid-state construction.

Key Specifications
• Amperage: 150 A
• Voltage Rating: 600 VAC max
• Poles: 3
• Frame Type: 2 (Power Defense PDG2)
• Interrupt Rating: 65 kA at 480 V
• Trip Unit: PXR10 LSI (Long-time, Short-time, Instantaneous)
• Mounting Type: Molded Case
• Weight: Approximately 4.83 lbs
• Dimensions: 6.5in length x 6in height x 8in width
• Certifications: Globally rated for international standards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23M0150B2NL
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSI - Long-Time, Short-Time and Instantaneous Trip
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679943397
• GTIN : 786679943397
• Country of Origin : Dominican Republic
• Dimensions : 6.5 in x 6 in x 8 in (Length/Depth x Height x Width)
• Weight : 4.83 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 521
