PDG23M0060TFFL - Eaton 60A 600V 3 Pole Molded Case Circuit Breaker Power Defense Frame 2

PDG23M0060TFFL

PDG23M0060TFFL is a 3 Pole Eaton Power Defense molded case circuit breaker rated for 60A at 600VAC, designed for reliable protection in commercial and industrial power distribution systems. This Eaton Power Defense circuit breaker features a thermal magnetic trip unit, bolt-on mounting, and a 65kAIC interrupt rating at 480VAC. It is globally rated, meets UL, CSA, IEC, and CCC standards, and is suitable for use in a wide range of applications requiring robust circuit protection.

• Part Number: PDG23M0060TFFL
• Manufacturer: Eaton
• Series: Power Defense
• Frame Type: Frame 2
• Amperage: 60A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65kAIC at 480VAC
• Protection Type: Thermal Magnetic
• Functions: Long Time and Instantaneous Trip
• Certifications: UL, CSA, IEC, CCC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23M0060TFFL
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078667986247
• GTIN : 00786679862476
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 505
