Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG23M0030MSAJ
PDG23M0030MSAJ is a 30 Amp, 600 VAC, 3 Pole molded case circuit breaker from Eaton's Power Defense PDG2 series designed for motor circuit protection.This circuit breaker features a Frame 2 design with adjustable thermal and magnetic trip units, standard line and load terminals, and a high interrupt rating of 65 kA at 480 VAC. It is globally rated and certified to UL, CSA, IEC, and CCC standards, making it suitable for a wide range of industrial applications requiring reliable motor protection.
- Amperage: 30 A
- Voltage Rating: 600 VAC
- Poles: 3
- Frame: 2
- Interrupt Rating: 65 kA at 480 VAC
- Trip Unit: Adjustable Thermal/Magnetic
- Terminals: Standard Line and Load
- Series: Power Defense PDG2
- Certifications: UL, CSA, IEC, CCC
- Mounting Type: Molded Case
Specifications
- Part Number: PDG23M0030MSAJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Section : Motor circuit protector
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 30
- AIC rating : 65kA@480V
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679325421
- Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
- Weight : 4.0586
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 490
