PDG23M0025TFFJ - Eaton 25A 600VAC 3-Pole Molded Case Circuit Breaker Frame 2 65kAIC T-M Trip

PDG23M0025TFFJ

PDG23M0025TFFJ is a three-pole, 25A molded case circuit breaker designed for reliable power distribution and protection in commercial and industrial applications. This Eaton Power Defense circuit breaker features a 600VAC rating, 65kA interrupt capacity at 480V, and a thermal-magnetic trip unit for precise overcurrent protection. It is globally rated, suitable for use in a wide range of electrical systems, and comes in a compact Frame 2 design for easy installation.

• Part Number: PDG23M0025TFFJ
• Manufacturer: Eaton
• Amperage Rating: 25A
• Voltage Rating: 600VAC
• Poles: 3
• Interrupt Rating: 65kAIC at 480V
• Frame: 2
• Series: Power Defense
• Mounting Type: Standard Line and Load
• Connection Type: Feed-Thru
• Trip Unit: Thermal-Magnetic (T-M)
• Certifications: UL 489, CSA, IEC 60947-2, CCC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23M0025TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78667921114
• GTIN : 00786679211144
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
