Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG23M0007MSAJ
PDG23M0007MSAJ is a three pole, 7 amp, 600 VAC molded case circuit breaker from Eaton's Power Defense Series, designed for reliable motor circuit protection in industrial applications. This circuit breaker features a thermomagnetic trip unit, adjustable instantaneous standard calibration, and is rated for 65 kAIC at 480 Vac. It is suitable for use in globally rated systems and includes lugs for secure mounting. The PDG23M0007MSAJ is UL, CSA, CCC, and IEC certified for safety and compliance.
- Part Number: PDG23M0007MSAJ
- Manufacturer: Eaton
- Amperage: 7 Amps
- Voltage: 600 VAC
- Poles: 3
- Frame: 2
- Interrupt Rating: 65 kAIC at 480 Vac
- Series: Power Defense PDG2
- Mounting Type: Lug Included
- Trip Unit: Thermomagnetic, Adjustable Instantaneous
- Certifications: UL, CSA, CCC, IEC
- Application: Motor Circuit Protection
Specifications
- Part Number: PDG23M0007MSAJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Section : Motor circuit protector
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 7
- AIC rating : 65kA@480V
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679216842
- Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
- Weight : 4.0586
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 498
