Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG23G0225E2CN - Eaton - Molded Case Circuit Breakers
PDG23G0225E2CN - Eaton - Molded Case Circuit Breakers is an Eaton Power Defense molded case circuit breaker designed for reliable protection in demanding electrical environments. This three-pole, 225A circuit breaker features a 600 Vac voltage rating and a 35kA interrupt rating at 480 Vac, making it suitable for a wide range of industrial and commercial applications. The breaker is part of the globally rated Power Defense series and is built to Frame 2 specifications for robust performance.
- Part Number: PDG23G0225E2CN - Eaton - Molded Case Circuit Breakers
- Manufacturer: Eaton
- Series: Power Defense
- Frame: 2
- Amperage Rating: 225A
- Poles: 3
- Voltage Rating: 600 Vac
- Interrupt Rating: 35 kAIC at 480 Vac
- Mounting Type: Fixed
- Trip Unit: Thermal Magnetic
- Certifications: UL Listed
Specifications
- Part Number: PDG23G0225E2CN - Eaton - Molded Case Circuit Breakers
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LSI - Long-Time, Short-Time and Instantaneous
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- Country of Origin : Dominican Republic
- Dimensions : Length 3.38in Height 6in Width 4.13in
- Weight : 4.9
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 493
