PDG23G0200TFFL - Eaton 200A 600V 3 Pole Molded Case Circuit Breaker, Power Defense Frame 2, 35kAIC @ 480V, Thermal Magnetic Trip

PDG23G0200TFFL

PDG23G0200TFFL is a 3 pole, 200A, 600V Eaton Power Defense molded case circuit breaker designed for reliable protection in commercial and industrial applications. This globally rated breaker features a thermal magnetic trip unit and a robust interrupting rating of 35kAIC at 480V, making it suitable for a wide range of power distribution needs.Engineered for durability and safety, the PDG23G0200TFFL offers standard line and load side lug connections, a compact frame size, and compliance with major international standards. Its globally rated design ensures compatibility across multiple markets and installations.

• Part Number: PDG23G0200TFFL
• Manufacturer: Eaton
• Series: Power Defense
• Frame: 2
• Amperage: 200A
• Voltage: 600VAC
• Poles: 3
• Interrupt Rating: 35kAIC @ 480V
• Protection Type: Thermal Magnetic
• Mounting Type: Standard Lug
• Standards: UL, CSA, IEC, CCC, RoHS
• Application: Commercial, Industrial Power Distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23G0200TFFL
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 35KA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic
• Trip Type : T-M (Fxd-Fxd) TU

Product Data

• UPC : 078667991200
• GTIN : 00786679912003
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 492
