PDG23F0080TFFL - Cutler Hammer 80A 600V 3-Pole Molded Case Circuit Breaker Frame 2 Thermal Magnetic Trip

PDG23F0080TFFL

PDG23F0080TFFL is a Cutler Hammer molded case circuit breaker designed for 80 amp, 600 volt AC applications with 3 poles and a Frame 2 size.This circuit breaker features a thermal magnetic trip unit with fixed instantaneous trip, a 25 kA interrupt rating at 480 VAC, and is suitable for three-phase power distribution. It supports wire sizes from 14 AWG to 1/0 AWG and complies with UL 489, CSA, IEC 60947-2, and CCC standards.

• Amperage: 80A
• Voltage Rating: 600 VAC
• Number of Poles: 3
• Frame Size: 225A / Frame 2
• Interrupt Rating: 25 kA at 480 VAC
• Trip Unit: Thermal Magnetic Fixed
• Wire Size Range: 14 AWG to 1/0 AWG
• Mounting Type: Standard Terminals Load Only
• Phase: Three
• Standards: UL 489, CSA, IEC 60947-2, CCC
• Dimensions (HxWxD): 6" x 4.11" x 3.5"
• Weight: 1.8 kg

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23F0080TFFL
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679923290
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
