Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG23F0080TFFJ
PDG23F0080TFFJ is a Cutler Hammer Eaton molded case circuit breaker designed for reliable power protection.This circuit breaker features an 80 ampere rating, 600 volt AC voltage rating, and 3 poles. It is a Frame 2 Power Defense (PDG) type with a 25kA interrupt rating at 480 volts, suitable for demanding industrial and commercial applications. The breaker uses a thermal-magnetic trip unit with long-time and instantaneous protection functions. It includes feed-thru connection type and meets UL 489 and ANSI C37 certifications.
- Manufacturer: Cutler Hammer Eaton
- Part Number: PDG23F0080TFFJ
- Amperage: 80 Amps
- Voltage: 600 VAC
- Poles: 3
- Frame Size: 2 (Power Defense PDG)
- Interrupt Rating: 25kA at 480 VAC
- Trip Unit: Thermal-Magnetic (LI - Long-Time)
- Connection Type: Feed-Thru
- Certifications: UL 489, ANSI C37
- Mounting Type: Molded Case
Specifications
- Part Number: PDG23F0080TFFJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 80
- Phase : 3
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679213452
- GTIN : 00786679213452
- Country of Origin : Dominican Republic
- Dimensions : 8 in x 6 in x 6 in (Length/Depth x Height x Width)
- Weight : 5 lb
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
