PDG22M0030TFFJ - Cutler Hammer 30A 600V 2 Pole Molded Case Circuit Breaker Frame 2 Thermal Magnetic

PDG22M0030TFFJ

PDG22M0030TFFJ is a 2 Pole molded case circuit breaker from Cutler Hammer, designed for reliable circuit protection in industrial and commercial applications. This breaker features a 30A current rating, 600V AC voltage rating, and a robust interrupt rating of 65 kAIC at 480V AC. It is part of the Power Defense series, with a Frame 2 design and a fixed thermal magnetic trip unit. The breaker is globally rated and suitable for chassis mounting with feed-thru connections. This breaker is ideal for use in power distribution systems where safety and durability are critical. Its thermal magnetic trip mechanism provides both overload and short-circuit protection, ensuring reliable performance in demanding environments.

• Part Number: PDG22M0030TFFJ
• Manufacturer: Cutler Hammer
• Series: Power Defense
• Frame: 2
• Poles: 2
• Current Rating: 30A
• Voltage Rating: 600V AC
• Interrupt Rating: 65 kAIC at 480V AC
• Mounting Type: Chassis Mount
• Connection: Feed-Thru
• Trip Unit: Fixed Thermal Magnetic
• Certifications: Globally Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG22M0030TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679276136
• GTIN : 00786679276136
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 69.9 mm (Length/Depth x Height x Width)
• Weight : 4.55143
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
