Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG22F0175TFFJ
PDG22F0175TFFJ is a 175 Amp, 600 Volt, 2 Pole molded case circuit breaker from Eaton's Power Defense series designed for panel mounting.This Eaton circuit breaker features thermal magnetic protection with long-time and instantaneous trip units, a 25 kA interrupt rating at 480V, and is UL, CSA, IEC, and CCC certified. It supports feed-thru connection and is suitable for three-phase applications with a frame size 2.
- Key Specifications
- Amperage: 175 A
- Voltage Rating: 600 Vac
- Poles: 2
- Mounting Type: Panel
- Interrupt Rating: 25 kA at 480 V
- Series/Frame: Power Defense, Frame 2
- Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
- Connection: Feed-Thru
- Certifications: UL, CSA, IEC, CCC
- Phase: 3
- Dimensions (HxWxD): 3.5 in x 6 in x 2.75 in
- Weight: 4.49 lbs
- Part Number: PDG22F0175TFFJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Section : Molded case circuit breaker
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 175
- Poles : 22
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- UPC : 786679316191
- Dimensions : 88.9 mm x 152.4 mm x 69.9 mm (Length/Depth x Height x Width)
- Weight : 4.55143
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 496
