PDG22F0150TFFJ - Cutler Hammer 150A 600V 2-Pole Molded Case Circuit Breaker

PDG22F0150TFFJ

PDG22F0150TFFJ is a 2-pole molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This Eaton Power Defense series breaker features a 150A amperage rating, 600VAC voltage rating, and a 25kA interrupt rating at 480V, making it suitable for demanding applications. The breaker uses feed-thru connections and includes a fixed thermal-magnetic trip unit for consistent performance. It is globally rated and built to meet rigorous safety standards. Key Specifications

• Part Number: PDG22F0150TFFJ
• Manufacturer: Cutler Hammer (Eaton)
• Series/Frame: Power Defense, Frame 2
• Amperage Rating: 150A
• Voltage Rating: 600VAC
• Poles: 2
• Interrupt Rating: 25kA at 480V
• Mounting Type: Feed-Thru
• Trip Unit: Fixed Thermal-Magnetic
• Connection Type: Standard Line and Load
• Certifications: Globally Rated
• Application: Commercial and Industrial Power Distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG22F0150TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679316597
• GTIN : 00786679316597
• Country of Origin : Dominican Republic
• Dimensions : 9 in x 6 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 3.2 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 495
