PDG13G0040TFFJ - Eaton 40A 600VAC 3-Pole Power Defense Molded Case Circuit Breaker Frame 1 Thermal Magnetic Trip

PDG13G0040TFFJ

PDG13G0040TFFJ is a 3-pole molded case circuit breaker from Eaton's Power Defense series rated for 40 amps and 600 VAC. It features a thermal magnetic trip unit and chassis mounting type.This Eaton PDG13G0040TFFJ circuit breaker provides reliable protection with a 35kA interrupt rating at 480 VAC and 22kA at 250 VDC. It is designed with a Frame 1 chassis mount and a T298 trip type for robust circuit protection in industrial and commercial applications. The breaker supports standard line and load connections and complies with UL and CSA certifications.

Key Specifications
• Amperage: 40A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Mounting Type: Chassis Mount
• Interrupt Rating: 35kA at 480 VAC, 18kA at 600 VAC, 22kA at 250 VDC
• Frame: 1
• Trip Unit: Thermal Magnetic (T298)
• Breaker Type: Power Defense Molded Case
• Line and Load: Standard
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG13G0040TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 3
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679274217
• GTIN : 00786679274217
• Country of Origin : Dominican Republic
• Dimensions : 7 in x 4.5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.8
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
