PDG13F0070TFFJ - Eaton 70A 600V 3 Pole Power Defense Molded Case Circuit Breaker Frame 1 TM Trip Unit

PDG13F0070TFFJ

PDG13F0070TFFJ is an Eaton Power Defense molded case circuit breaker designed for reliable circuit protection.PDG13F0070TFFJ features a 70 ampere rating, 600 VAC voltage rating, and a 3-pole configuration with a Frame 1 size. It includes a TM (Fixed-Fixed) trip unit and offers a 25kA interrupt rating at 480 VAC, suitable for demanding industrial and commercial applications. This breaker is globally rated and designed for standard line and load connections.

• Amperage: 70A
• Voltage Rating: 600 VAC max
• Poles: 3
• Frame: 1
• Interrupt Rating: 25kA at 480 VAC
• Trip Unit: TM (Fixed-Fixed)
• Mounting Type: Bolt-On
• Series: Power Defense
• Certifications: Globally Rated
• Standard Line and Load connections

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG13F0070TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480VAC
• Connection : Bolt-On
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679276266
• GTIN : 00786679276266
• Country of Origin : Dominican Republic
• Dimensions : 76 mm x 114.3 mm x 76.2 mm (Length/Depth x Height x Width)
• Weight : 2.731081
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
