Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG12M0030TFFJ
PDG12M0030TFFJ is a Cutler Hammer Power Defense series molded case circuit breaker rated for 30 amps and 600 volts with 2 poles.This thermal magnetic circuit breaker features a 65kA interrupt rating at 480V, Frame 1 size, and fixed-fixed trip unit. It is designed for chassis mounting and provides reliable circuit protection in industrial and commercial applications. The breaker supports both 600 VAC and 250 VDC ratings and meets global certification standards.
- Amperage: 30 Amps
- Voltage: 600 VAC / 250 VDC
- Poles: 2
- Interrupt Rating: 65kA @ 480V
- Series/Frame: Power Defense Frame 1
- Trip Unit: Thermal Magnetic (Fixed-Fixed)
- Mounting Type: Chassis Mount
- Certifications: Globally Rated
- Product Width: 50.8 mm
- Weight: 0.907 kg
Specifications
- Part Number: PDG12M0030TFFJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 30
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679252758
- GTIN : 00786679252758
- Country of Origin : Dominican Republic
- Dimensions : 76 mm x 139.7 mm x 50.8 mm (Length/Depth x Height x Width)
- Weight : 2.02261
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
