Description
P3F365GN
P3F365GN is a three-pole fusible plug-in unit designed for Eaton Pow-R-Way III busway systems, rated at 400 Amps and 600 Volts with R class fuses. This busway plug features 50% internal ground and 100% neutral configuration, delivering a 200kA@600V interrupt rating for reliable power distribution in industrial and commercial applications. The unit measures 48.85 inches in height, 21.22 inches in width, and 10.07 inches in depth, with an approximate weight of 77 pounds.
- Amperage Rating: 400A
- Voltage Rating: 600V
- Number of Poles: Three-pole
- Fuse Type: R class
- Grounding: 50% Internal
- Neutral: 100%
- Interrupt Rating: 200kA@600V
- Series: Pow-R-Way III
- Certifications: UL 857, CSA Certified, ANSI IEEE Certified
- Application: Busway
Specifications
- Part Number: P3F365GN
- Manufacturer : Eaton
- Category : Bus Plug
- Item Subcategory : Fusible
- Family : POW-R-WAY III
- Type : P3F
- Voltage : 600
- Amperage : 400
- Phase : 3
- AIC rating : 200kA@600V
- Fuse Class : R,H,J
- Wire : 4
Product Data
- Weight : 85
