P12 - Vishay Fully Sealed Container Cermet Potentiometer 270° Travel 22Ω to 10MΩ Linear Taper

P12

P12 is a fully sealed container cermet potentiometer designed for professional and military-grade applications requiring high reliability and precision. This potentiometer features a cermet resistive element, 270° ± 10° electrical travel, and a wide resistance range from 22 Ω to 10 MΩ for linear taper and 100 Ω to 2.2 MΩ for logarithmic taper. It offers a mechanical travel of 300° ± 5°, a maximum torque of 2 Ncm, and a mechanical endurance of 25,000 cycles. The device is available with standard or on-request tolerance and taper options, and is suitable for environments requiring robust sealing and long-term stability.

• Resistive element: Cermet
• Electrical travel: 270° ± 10°
• Resistance range (linear): 22 Ω to 10 MΩ
• Resistance range (logarithmic): 100 Ω to 2.2 MΩ
• Tolerance: ± 20 % (standard), ± 10 % (on request)
• Power rating: 1 W (linear), 0.5 W (logarithmic) at +70 °C
• Limiting element voltage (linear): 350 V
• Dielectric strength: 2000 V RMS
• Insulation resistance: 106 MΩ at 500 VDC
• Mechanical travel: 300° ± 5°
• Mechanical endurance: 25,000 cycles
• Operating temperature: See Standard Resistance Element Data

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: P12
• Manufacturer : Sepco
• Brand : Sepco
• Category : Conduit & Fittings
• Item Subcategory : Rigid Steel Conduit Fittings

Product Data

• UPC : 078599414121
• GTIN : 00785994141211
• Weight : 5.19
